HT.HP. Soft flow
HTHP Soft flow
- First and foremost, HTHP Soft Flow Dyeing Machine is suitable for sensitive surface structures and natural fabrics. All fabrics like cotton, wool, viscose, acrylic and blends of jersey, terry towel, velour and nylon.
- Secondly, HTHP Soft Flow Machine is a contemporary technology that uses a curved nozzle to transfer the cloth smoothly at a high fluid flow. As a result, reduce strain and avoid creases and peeling.
- Thirdly, by the new design, HTHP Soft Flow takes the Lowest liquor ratio up to 1:5 (on wet material) instead of the conventional design taking the liquor ratio up to 1:10 (on wet).
- Fourthly, HTHP Soft Flow is made of high-quality steel inside and out, making it rust-resistant.
- Fifthly, the nozzles inside HTHP Soft Flow come with 316L Quality stainless steel. It gives smooth operation to the cloth.
- Lastly, HTHP Soft Flow includes numerous safety features.
In conclusion, it is perfect for modern textile dyeing plants.
🔸 Technical Specification
✅ Lowest liquor ratio up to 1:5 (wet Fabric)
✅ Capacity: 50 to 2000 kg.
✅ Dye –30 To 500 Grms/Mtr. Sq. Fabrics (Woven & Knitted Fabrics)
✅ High Temp. – Up to 140° C.
✅ The vessel builds from stainless steel SS 316L Quality.
➡ Online filter for easy clean-up even during the process with an extra filter mesh.
➡ For smooth fabric circulation, a Teflon Sheet is inside the chamber.
➡ Cup type very soft nozzle with low pressure & higher volume design.
➡ The fabric driving reel comes with a frequency controller.
₹1,250,000.00
Compare
HTHP Soft flow
- First and foremost, HTHP Soft Flow is suitable for sensitive surface structures and natural fabrics. All fabrics like cotton, wool, viscose, acrylic and blends of jersey, terry towel, velour and nylon.
- Secondly, HTHP Soft Flow is a contemporary technology that uses a curved nozzle to transfer the cloth smoothly at a high fluid flow. As a result, reduce strain and avoid creases and peeling.
- Thirdly, by the new design, HTHP Soft Flow takes the Lowest liquor ratio up to 1:5 (on wet material) instead of the conventional design taking liquor ratio up to 1:10 (on wet).
- Fourthly, HTHP Soft Flow is made of high-quality steel inside and out, making it rust-resistant.
- Fifthly, the nozzles inside HTHP Soft Flow come with 316L Quality stainless steel. It gives smooth operation to the cloth.
- Lastly, HTHP Soft Flow includes numerous safety features.
In conclusion, it is perfect for modern textile dyeing plants.
🔸 Technical Specification
✅ Lowest liquor ratio up to 1:5 (wet Fabric)
✅ Capacity: 50 to 2000Kg.
✅ Dye –30 To 500 Grms/Mtr. Sq. Fabrics (Woven & Knitted Fabrics)
✅ High Temp. – Up to 140° C.
✅ The vessel build from stainless steel SS 316L Quality
➡ Online filter for easy clean-up even during the process with an extra filter mesh.
➡ For smooth fabric circulation, a Teflon Sheet inside the chamber.
➡ Cup type very soft nozzle with low presser & higher volume design.
➡ The fabric driving reel comes with a frequency controller.
🔸 Payment, Taxes and Delivery
Payment: Before dispatch, 40% advance & balance against Proforma Invoice.
Delivery: Delivery of the machinery ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% (Domestic Orders) Or Vat 4% +1% No CST against form “H”( export orders).
Erection: Will be charged extra per machinery over and above price.
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
| Capacity 125 Kgs/ Chamber | NA, 25 Kgs, 50 Kgs, 75 Kgs, 100 Kgs, 125 Kgs, 250 Kgs, 375 Kgs, 500 Kgs, 625 Kgs, 750 Kgs, 875 Kgs, 1000 Kgs, 1125 Kgs, 1250 Kgs, 1375 Kgs, 1500 Kgs, 1625 Kgs, 1750 Kgs, 1875 Kgs, 2000 Kgs |
|---|---|
| Capacity 150 Kgs/ Chamber | NA, 150 Kgs, 300 Kgs, 450 Kgs, 600 Kgs, 750 Kgs, 900 Kgs, 1050 Kgs, 1200 Kgs, 1350 Kgs, 1500 Kgs, 1750 Kgs, 1900 Kgs |
| Nossel size | 105mm, 120mm, 140mm, 200mm, 250mm, 300mm |
| Fabric | COTTON, WOOL, ACRYLIC, VELOUR, NYLON, KNITTED |
Dimensions
Based on 0 reviews
Be the first to review “HT.HP. Soft flow”
-
Processing Machinery
Chainless Merceriser
Chainless Merceriser
The Chainless Merceriser is the most Significant procedure for the cloth. Chainless Merceriser machine there are following features in it.
- To begin with, Chainless Merceriser is one of the most fundamental steps for finishing cotton fabrics. Merceriser involves treating organic material with high-caustic soda solutions. In other words, it eliminates impurities or undesired particles from the cloth before completing other processes.
- Secondly, It rolls cloth on batching trolley from fold/loose form by pressure roll assisted with twin – Pneumatic Cylinders, AC Motor & Gearbox.
- Thirdly, The caustic soda-impregnated Fiber reflects light, making it brighter. It also boosts hygroscopicity, strength, and dye affinity.
- Fourthly, The operating width of a chainless merceriser can range from 1500mm to 3500 mm, as preferred by the customer.
- Fifthly, It can process woven fabrics with capacities ranging from 70 to 700 grammes per square metre.
- Lastly, It is available in various sizes and speeds ranging from 8 to 40 metres per minute.
In conclusion, this merceriser machine is best suitable for the garment industry Dyeing & printing plants.
🔸 ADVANTAGES :
➡ Increase dye Affinity
➡ Improve Luster
➡ Add more Tensile Strength
➡ Increase Dimensional Stability of Warp & Weft yarn.
➡ Elimination of immature or Dead Cotton
➡ Improved Handling effects.
➡ Tailored to the customer’s specifications.
SKU: P/CM-1 -
Finishing Machinery
Compressive Shrinking Range
The Sole purpose of the Controlled Compressive Shrinking Range or ZEROZERO is to ensure that the garment made from such fabric does not shrink after the wash hence perfect dimensional stability.
As per standard, + / -1 % residual shrinkage is acceptable. Controlled Compressive Shrinking Range or ZEROZERO are available up to 3200mm working width fabric to assure total shrinkage protection to woven fabrics. It can be 100% cotton, cotton/polyester, cotton/viscose or tough and heaviest fabric like denim. Compressive Shrinking Range or ZEROZERO developed in a way that can shrinkage up to 12% in a single passage.
The most capable of shrinking medium, lightweight fabric to the heaviest denim, cotton blended suiting & shirting by watering cotton, terylene, hemp and its blends to shrink the cloth to meet the requirements of shrinkage, stabilization and improve the hand touch.
A controlled Compressive Shrinking Range is usually the last process in the sequence of fabric finishing. The woven fabric processed in the machine gets fully shrunk.
Before compressive shrinking, it is advisable to establish the width at which the cloth should get shrunk in length to meet the requirement of the garment makers. It is the best Fabric Finishing machinery.
🔸 Technical Specification
✅ A.C. frequency conversion transmission, designed speed: 10-80m/minute.
✅ Shrinkage 0 – 12 % depending upon fabric quality.
✅ Minimum and controlled tension.
⭕ Imported Rubber Blanket and Polyester Felt will be provided optionally.
✅ A Jacketed drum in 1500mm, 2000mm and 2500mm diameters.
✅ Stainless Steel damping & conditioning unit supplied as standard Parts.
SKU: n/a -
Dyeing Machinery
Hydraulic Jigger
Hydraulic Jigger
Hydraulic Jigger is a piece of revolutionary equipment for open-width Scouring, Bleaching & Dyeing processes in batch form. One of the best Dyeing machinery with perfect dyeing results. Hydraulic Jigger has the following features:
- Firstly, Hydraulic Jigger’s Adjustable tension according to Fabric quality ensures perfect pre-treatment and dyeing irrespective of run lengths for the same shade/colour. In other words, Hydraulic Jigger dyes the Clothing rapidly with accuracy.
- Secondly, Hydraulic Jigger comes with closed chambers with doors that close while the operation is performing. Which gives it desired temperature in less time. Therefore, less wastage of resources.
- Thirdly, Consistent dyeing of the same shade for any number of times in the future, Moreover the highly efficient washing system saves washing time and precious Water. The uniform tension, process time, and ideal temperature contribute to the dying quality.
- Fourthly, Hydraulic Jigger controls these parameters resulting in fully controllable and reproducible shades. The controlled temperature and a steady circulation of dye liquid for flawless dyeing. PLC aided operation for repeatability. Suiting, shirting, and delicate fabrics such as rayon are best suited.
- Fifthly, the Hydraulic Jigger is available in 500kg and 1000kg capacity from 1200mm to 3000mm working width depending on the client’s need. Fabric ranging from 70 to 700 gsm/meter square of woven material may be dyed in a Hydraulic Jigger, making it ideal for Suiting, Shirting, and Delicate textile such as rayon.
Above all, flawless synchronisation of linear speed results in tension-free and crease-free fabric conveyance throughout the process.
🔸 Technical Specification
➡ Automatic reversal at the end of each cycle setting
➡ Spray washing through a selector switch
➡ Stopping the machine at the pre-determined sampling point
➡ Water filling through rotary switch
➡ Drain through a selector switch
➡ Digital Speed indication
➡ Speed setting through P L C
➡ Replenishing from dosing tank through valve
➡ Indirect steam heating through Heat Exchanger
➡ Temperature Controller.
➡ A valve adjusts the tension on the cloth.
➡ Soft Start & Stop
➡ Pendulation when adding and emptying liquid
➡ Touch Screen
➡ Specially designed software for the machine
SKU: n/a -
Processing Machinery
Cylinder Drying Range
Drying Range
The Drying Range or VDR (Vertical Drying Range Machine) is one of the most demanding processing machinery in Woven dyeing & printing plants. The Drying Range has the following features that make it an essential part of the plant.
- Firstly, It ensures rapid drying of fabric at high steam pressure.
- In other words, It is suitable for fabric drying, semi-drying, and fabric that doesn’t require heat setting or Clothes which need semi-dry or completely dry.
- Secondly, a Belt drive or individual drive for tensionless and crease-free passage of fabric on the cylinder result in the cloth moving smoothly.
- Thirdly, an Individual trapping system for faster condensate removal inside chambers.
- Therefore, it keeps cylinders at maximum heat.
- Fourthly, the working width options from 1250mm to 3500mm according to the client’s need.
- Fifthly, ranging from 70 gsm/meter square up to 700 gsm/meter square of woven fabrics like cotton, viscose, rayon, wool & polyester can be rolled on this machine.
- Sixthly and most Important Drying Range has the option of 6, 8, 10, 12, 16, 20, or 24 cylinders in a single or double frame.
Above all, more numbers of cylinders equal more speed.
In conclusion, this machine is best suitable for Dyeing and Printing Plants.
🔸 Advantages:
➡ Long Lasting & sturdy construction
➡ Lowest consumption data
➡ Quick heating up
➡ Easy to operate
➡ Drying with minimum tension
➡ Crease-free fabric passage
➡ Perfect temperature uniformity across fabric width
➡ Highest product quality
➡ Shut off valves for cylinders
➡ Lowest maintenance effort
➡ Lowest radial run out and perfect welding craftsmanship
🔸 Technical Specification:
✅ Box type or beam stack structures as per choice.
✅ Belt-driven or individual drive for tension-less and crease-free passage for fabric on cylinders.
✅ Options of 2 bowls or three bowls mangle to attached with cylinder dryer as per customer need.
✅ Any width from 1250mm to 3500mm of the dryer is supplied.
✅ The Drying Range has the option of 6, 8, 10, 12, 16, 20, or 24 cylinders in a single or double frame.
✅ Every/alternate cylinder can have an individual geared motor drive if required.
✅ An Individual trapping system for faster condensate removal from cylinders.
SKU: n/a -
Accessories
A Frame
A-FRAME Trolley
A-Frame trolley is one of the most required Accessories in Textile Plant and Mills. A-frame’s objective is to carry the fabric and make it easy to manoeuvre inside the facility while different processes such as measuring, washing, cleaning, dyeing or printing, and finishing.
A-frame trolleys are also Utilised in rotating stations by simply adding an extension to them.
A-frame trolleys come in different sizes from 44 to 130 inches roller width depending on the customer. A-frame trolleys take less space than bucket/box-type trolleys. It gets easier to manage them and store them in one place.
Inshot A-Frame Tolleys are best to manage and store the grey to finished material in a clean and sorted way that helps to identify the fabric lot.
Many Textile mills and Export houses have been using it for a long time, making it reliable and one of the solutions to manage the fabric.
🔸 Technical Specification
✅ A FRAME’s top roll fabricate from M.S. Seamless Pipe (Ebonite quoting).
✅ The end shaft is RIB constructed or As per the buyer’s suggestion.
⭕ Cladding of S.S. Sheet on a batch roll. (Optional)
✅ The front side pooling system is a swivel-type M.S. fabricated bracket with 10″ x 2 wheels.
✅ The rare side is of fixed type 12″ x 3″ wheel.
✅ Batch coupling is fit on a batch roll for rotating.
✅ A-FRAME is manufactured from an M.S. channel (100/50mm) x 6mm wall thickness.
SKU: A/T-1 -
Dyeing Machinery
Atmospheric Soft Over Flow
Atmospheric Soft flow
The Atmospheric Soft Flow machine is the same as HTHP Soft flow Dyeing machine. The only difference is Atmospheric Soft Flow works at low temperatures & without pressure.
Some fabrics like Cotton & Cotton blends don’t require high temperatures. In that case, Soft Flow is very much suitable because Atmospheric Soft Flow reduces the running cost by saving energy. In short, it is a Cotton dyeing machine.
Furthermore, the liquor ratio of the Soft Flow machine is lower than that of the HTHP Soft Flow machine.
🔸 Technical Specification
✅ Lowest liquor ratio up to 1:4 (wet Fabric)
✅ Capacity: 50 to 1200 kg.
✅ Dye –30 To 500 Grms/Mtr. Sq. Fabrics (Woven & Knitted Fabrics)
✅ Maximum Temprature – Up to 98° C.
✅ The vessel builds from stainless steel SS 316L Quality.➡ Online filter for easy clean-up even during the process with an extra filter mesh.
➡ For smooth fabric circulation, a Teflon Sheet is inside the chamber.
➡ Cup type very soft nozzle with low pressure & higher volume design.
➡ The fabric driving reel comes with a frequency controller.
SKU: D/ASF-1
Related products
-
Dyeing Machinery
Semi Automatic Jigger Machine
Semi Automatic Dyeing Jigger
Roll Center 31″ (790 mm) – 36″ (915mm)
Capacity 350-500 Kg. (250 gsm)
Batch Dia 900-1100 mm
Available Width : 48″ To 150″ Roller WidthSemi Automatic Jumbo Jigger Machine
Roll Center 31″ (790 mm) – 36″ (915mm)
Capacity 350-500 Kg. (250 gsm)
Batch Dia 900-1100 mm
Available Width : 48″ To 150″ Roller Width[spbsm-follow-buttons]
SKU: n/a -
Dyeing Machinery
Long Tube Jet
Long tube Jet dyeing machine working concept is same compare with Convention Rapid long tube jet dyeing machine. Though the major advantage of this machine is liquor ration is nearly half than conventional rapid Jet dyeing machine. In this machine fabric does not float but it run nearly in dry condition. Another benefit of this machine is it’s single vessel with two chamber design. Due to this design fabric loop length is reduce additionally bringing down the running cost, capital cost as well as processing time.
[spbsm-follow-buttons]
SKU: n/a -
Dyeing Machinery
Hydraulic Jigger
Hydraulic Jigger
Hydraulic Jigger is a piece of revolutionary equipment for open-width Scouring, Bleaching & Dyeing processes in batch form. One of the best Dyeing machinery with perfect dyeing results. Hydraulic Jigger has the following features:
- Firstly, Hydraulic Jigger’s Adjustable tension according to Fabric quality ensures perfect pre-treatment and dyeing irrespective of run lengths for the same shade/colour. In other words, Hydraulic Jigger dyes the Clothing rapidly with accuracy.
- Secondly, Hydraulic Jigger comes with closed chambers with doors that close while the operation is performing. Which gives it desired temperature in less time. Therefore, less wastage of resources.
- Thirdly, Consistent dyeing of the same shade for any number of times in the future, Moreover the highly efficient washing system saves washing time and precious Water. The uniform tension, process time, and ideal temperature contribute to the dying quality.
- Fourthly, Hydraulic Jigger controls these parameters resulting in fully controllable and reproducible shades. The controlled temperature and a steady circulation of dye liquid for flawless dyeing. PLC aided operation for repeatability. Suiting, shirting, and delicate fabrics such as rayon are best suited.
- Fifthly, the Hydraulic Jigger is available in 500kg and 1000kg capacity from 1200mm to 3000mm working width depending on the client’s need. Fabric ranging from 70 to 700 gsm/meter square of woven material may be dyed in a Hydraulic Jigger, making it ideal for Suiting, Shirting, and Delicate textile such as rayon.
Above all, flawless synchronisation of linear speed results in tension-free and crease-free fabric conveyance throughout the process.
🔸 Technical Specification
➡ Automatic reversal at the end of each cycle setting
➡ Spray washing through a selector switch
➡ Stopping the machine at the pre-determined sampling point
➡ Water filling through rotary switch
➡ Drain through a selector switch
➡ Digital Speed indication
➡ Speed setting through P L C
➡ Replenishing from dosing tank through valve
➡ Indirect steam heating through Heat Exchanger
➡ Temperature Controller.
➡ A valve adjusts the tension on the cloth.
➡ Soft Start & Stop
➡ Pendulation when adding and emptying liquid
➡ Touch Screen
➡ Specially designed software for the machine
SKU: n/a -
Dyeing Machinery
Top Tube Soft Flow
Top Tube Soft flow dyeing machine very much suitable to process delicate woven & knitted fabrics. It’s soft nozzle decrease tension further avoid problems like crease marks, rope marks, shrinking etc.
Another benefit of this machine is its single vessel two chamber design reduce fabric loop length as well as processing time.
[spbsm-follow-buttons]
SKU: n/a
There are no reviews yet.
