Double Folding & Plating
Is to be use for multiple applications, In this Double Folding machine there are following features in it.
- Firstly, it does cross fold to make it easy to organize batches which take less space. In other words, less space and more batches to place.
- Secondly, it fold fabric in platting from loose/roll form
- Thirdly, it also measure the fabric by optional given meter counter.
- Fourthly, Machine working width can be made from 41″/36 (Small)* to 72″/67 (Large) depending on client’s need.
- Fifthly, Fabric ranging from 70 gsm/meter square up to 700 gsm/meter square of woven fabrics like cotton, viscose, rayon, wool & polyester can be fold on this machine.
- Sixth and most importantly the speed can be achieve up to 50 meters per minute while preforming the process.
In conclusion, this machine is best suitable for Dyeing & Printing Units or Export house.
Starting From ₹275,000.00
Double Folding
Is to be use for multiple applications, In this Double Folding machine there are following features in it.
- Firstly, it does cross fold to make it easy to organize batches which take less space. In other words, less space and more batches to place.
- Secondly, it fold fabric in platting from loose/roll form
- Thirdly, it also measure the fabric by optional given meter counter.
- Fourthly, Machine working width can be made from 41″/36 (Small)* to 72″/67 (Large) depending on client’s need.
- Fifthly, Fabric ranging from 70 gsm/meter square up to 700 gsm/meter square of woven fabrics like cotton, viscose, rayon, wool & polyester can be fold on this machine.
- Sixth and most importantly the speed can be achieve up to 50 meters per minute while preforming the process.
In conclusion, this machine is best suitable for Dyeing & Printing Units or Export house.
Technical Specification
- Working Table descends upto 15” (380mm) in height.
- Cast Iron side walls are closed to make machine robust & Sturdy.
- Compensating device to release the Cloth tensionless and without curls creases.
- Length of Folds regulable from 1.00meter to 1.20meter(on request).
- Folding blades are mounted on the carriage of special steel roller chains.
- A simple device for quick & exact adjustment of folding blade.
- Doubling controlled manually or automatically following selvedge.
- Doubling Triangle adjustable.
- A mechanical or automatic table lowering device to lower the Folding Table at each folding operation. This system is regulated manually in order to adopt the machine to any kind of fabric (on request).
- Working width for Cloth to be doubled up to 3500mm.
- Stroke type length Counter with manual setting or Digital counter.
- Driving by motor 2HP x 960rpm.
- Speed : 50meters/minute.
Payment, Taxes and Delivery
Payment: 50% Advance online & Balance against Proforma Invoice prior to dispatch.
Delivery: Delivery of machine is ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% Or Vat 4% +1% No CST against form “H”( export orders).
Erection: Will be charged extra per machine over and above given price.
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
| Table Size | 41” / 36”, 55” / 50”, 65” / 60”, 72” / 67” |
|---|
