Automatic Jigger
Automatic JIGGER is one of the best dyeing machine inventions for simplifying the dying process. Automatic JIGGER is a Hybrid of hydraulic & conventional JIGGER.
Automatic JIGGER comes with two types 1st one is OPEN TYPE & other one is CLOSE TYPE.
Where One-hand OPEN TYPE Automatic JIGGER comes with all the benefits like
✅ Auto tension control
✅ Auto speed control
✅ Auto cycle control
✅ Circulation system with filters to avoid centre to selvedge
✅ Suitable for any exhaust pre-treatment, dyeing & finish process
✅ Tension setting device to avoid running crease & machine jerks
⭕ Auto pendulum control (optional)
⭕ Batching or winch device (optional)
⭕ Auto water level controller (optional)
⭕ Pneumatic operated drain (optional)
Otherhand CLOSE TYPE Automatic JIGGER comes with the additional features like
✅ Auto circulation system
✅ Auto temperature controller
✅ A fully covered jigger will save utilities
⭕ Dosing side tank facility (optional)
⭕ Circulation system with filters to avoid centre to narrow border (optional)
The tension control system allows Automatic JIGGER to dye any fabric with ease. One operator can run four Automatic JIGGER machines simultaneously thanks to its PLC system, and the individual drive “automatic dyeing jigger” runs on zero tension on the fabric.
Automatic JIGGER uses both rollers powered by separate gearboxes and motors on inverter drives which do wonders for uniform dyes, even when running at varying speeds.
In conclusion, it is the best-woven dyeing machine, fabric dyeing machine or Cotton dyeing machine.
🔶 Technical Specification
✅ Capacity: 300 Kg. to 2000 kg. [OPEN]
✅ Capacity: 500 Kg. to 2000 kg. [CLOSE]
✅ Available Width: 1250mm to 3400mm
✅ S.S. Structure 304 Out Outer body 316 mail rolls plus inner bottom
✅ 0 to 10 Kgs. (Tension less operation Possible)
✅ Suitable for any Fabric from 30gsm to 500gsm
✅ S.S. Cladded Main Roll
✅ Pneumatic cylinders operated doors [CLOSE]
✅ Individual drive on each roller
✅Speed & tension control through a drive
₹550,000.00
Compare
AUTOMATIC JIGGER
Automatic JIGGER is one of the best dyeing machine inventions for simplifying the dying process. Automatic JIGGER is a Hybrid of hydraulic & conventional JIGGER.
Automatic JIGGER comes with two types 1st one is OPEN TYPE as well 2nd one is CLOSE TYPE.
Where One-hand OPEN TYPE comes with all the benefits like
✅ Auto tension control
✅ Auto speed control
✅ Auto cycle control
✅ Circulation system with filters to avoid centre to selvedge
✅ Suitable for any exhaust pre-treatment, dyeing & finish process
✅ Tension setting device to avoid running crease & machine jerks
⭕ Auto pendulum control (optional)
⭕ Batching or winch device (optional)
⭕ Auto water level controller (optional)
⭕ Pneumatic operated drain (optional)
Otherhand CLOSE TYPE comes with the additional features like
✅ Auto circulation system
✅ Auto temperature controller
✅ A fully covered jigger will save utilities
⭕ Dosing side tank facility (optional)
⭕ Circulation system with filters to avoid centre to the edge (optional)
The tension control system allows dyeing nearly any fabric automatically with ease. One operator can run four machines simultaneously thanks to its PLC system, and the individual drive “automatic dyeing jigger” runs on zero tension on the fabric.
It uses both rollers sets powered by separate gearboxes and motors on inverter drives which can do wonders for giving uniform dyes, even when running at varying speeds.
🔶 Technical Specification
✅ Capacity: 300 Kg. to 2000Kg. [OPEN]
✅ Capacity: 500 Kg. to 2000Kg. [CLOSE]
✅ Available Width : 1250mm to 3400mm
✅ S.S. Structure 304 Out Outer body 316 mail rolls plus inner bottom
✅ 0 to 10 Kgs. (Tension less operation
Possible)
✅ Suitable for any Fabric from 30gsm to 500gsm
✅ S.S. Cladded Main Roll
✅ Pneumatic cylinders operated doors [CLOSE]
✅ Individual drive on each roller
✅Speed & tension control through a drive
🔶 Payment, Taxes and Delivery
Payment: Before dispatch of machinery, 40% advance and a balance against the proforma invoice.
Delivery: Delivery of machine ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% (Domestic Orders) Or Vat 4% +1% No CST against form “H”( export orders).
Installation: Will be charged extra per machine over and above the price.
OPEN TYPE
CLOSE TYPE
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
Automatic Jigger | Best Fabric dyeing machine 300-2000 kgs. | Book Online
Automatic jigger is a new fabric dyeing machine or say hybrid version of a simple jigger and hydraulic jigger this jigger can dye all woven fabrics like cotton.
Product SKU: D/AJ-1
Product Brand: Indian
Product Currency: ₹
Product Price: 550000
Price Valid Until: 2023-08-01
Product In-Stock: PreOrder
5
| Type | OPEN, CLOSE |
|---|---|
| Capacity | 300 Kg, 350 Kg, 500 Kg, 750 Kg, 1000 Kg, 1250 Kg, 1500 Kg, 1750 Kg, 2000 Kg |
| Machine width | 1250mm, 1400mm, 1500mm, 1600mm, 1800mm, 2000mm, 2200mm, 2400mm, 2600mm, 2800mm, 3000mm, 3200mm, 3400mm |
| Fabric | Cotton, Cotton Polyester, Wool, Canvas |
Automatic Jigger | Best Fabric dyeing machine 300-2000 kgs. | Book Online
Automatic jigger is a new fabric dyeing machine or say hybrid version of a simple jigger and hydraulic jigger this jigger can dye all woven fabrics like cotton.
Product SKU: D/AJ-1
Product Brand: Indian
Product Currency: ₹
Product Price: 550000
Price Valid Until: 2023-08-01
Product In-Stock: PreOrder
5
Youtube
Automatic Jigger | Best Fabric dyeing machine 300-2000 kgs. | Book Online
Automatic jigger is a new fabric dyeing machine or say hybrid version of a simple jigger and hydraulic jigger this jigger can dye all woven fabrics like cotton.
Product SKU: D/AJ-1
Product Brand: Indian
Product Currency: ₹
Product Price: 550000
Price Valid Until: 2023-08-01
Product In-Stock: PreOrder
5
Based on 0 reviews
Be the first to review “Automatic Jigger”
-
Accessories
Roll Wrapping
Roll Wrapping
Fabric Roll wrapping machine is one of the most required Accessories for pre-delivery processes in Textile plants and Mills. The primary object of the fabric roll wrapping machine is to wrap ready-to-ship rolls so that the fabric remains safe while being delivered to the customer.
Fabric Roll wrapping machines can wrap material rolls of Denim Cloth, Curtain Cloth, Carpets, Foam sheets, Upholsteries, Fabrics, Film, Paper etc. which have a Maximum roller height from ground level up to 400 millimetres.
The fabric Roll wrapping machine is simple to operate, and the sturdy & safe control panel makes it easy to load and unload the fabric roll with the ease of integration into conveyor lines.
With a speed of up to 50 meters per minute, making 20 to 40 rolls per hour while performing variable overlap, amount of stretch, and roller speed, the fabric roll wrapping machine saves labour, time and money.
Because of its unique construction, traverse can accommodate a variety of roll widths. Maximum stretch Power Roller Pre-Stretch Carriage with Pre-Stretch Ratio adjustable up to 300% (Depending upon Film Gauge & Quality).
Inshot fabric Roll wrapping/Stretch wrap machines make it possible to wrap, store and protect ready-to-ship rolls while protecting rolls from dirt and damage.
Many Textile mills and Export houses have been using it for a long time, making it reliable and one of the solutions to manage the fabric.
🔸 Technical Specification
✅ Maximum roller height from ground level up to 400mm can be processed.
✅ Speed up to 50 meters/minute.
✅ Maximum stretch Power Roller Pre-Stretch Carriage with Pre-Stretch Ratio adjustable up to 300% (Depending upon Film Gauge & Quality).
✅ Rolls/Hour: 20-40 rolls.
✅ Weight/Roll: 400kgs
✅ Roll Diameter: 600mm
✅ Roll Width: 2100mm (As Par Fabric width)
SKU: A/WR-1-1 -
Dyeing Machinery
CP Dyeing
CP Dyeing
CP Dyeing is dyeing machinery to Dye Fabrics rapidly. Dye Fabric. This machine has the following features.
- First, it dyes the cloth with reactive colours. The CP Dyeing is installed with a small vat & shaped to allow fabrics an adequate contact time for absorbing dye bath through the high speed of cloth.
- In other words, CP Dyeing dyes the cloth rapidly, with less place required.
- Secondly, Reduced liquor volume is possible due to the fast exchange of fluid. Therefore, less wastage of resources.
- Thirdly, CP Dyeing‘s Roller width can be made from 1200mm to 3000mm depending on the client’s need.
🔶 Special Features:
✅ Versatile because it is equally suitable for Light and Heavy fabrics.
✅ Utilising of “Two Nip Two Dip” method ensures consistent colour penetration.
✅ The Top rubber roller is anti-deflecting construction.
✅ On Nips, pneumatic loading can be as much as 6 tons.
✅ Minimum loss of dye liquor because of low Dye liquor content in the trough.
✅ The main Batcher can batch cloth up to 1500mm Dia.
✅ Drive to both padder & Batcher by inverter-controlled AC Drive.
✅ Minimum tension between padder & Batcher is for perfect winding of cloth.
✅ The minimum distance between Padder & Batcher is to avoid oxidation.
✅ Machines are available from 1200mm to 3000mm roller width.
SKU: n/a -
Washing Machinery
Open Width Washing Range
Open width Washing Range
Open width Washing Range is for the fabric washing machine for woven fabrics. The Open width Washing Range machine has the following features.
- Firstly, The system consists of a specially shaped impeller in the drum in which water jets uniformly smashes the full fabric width very high washing performance on the upper and backside of the fabric.
- In other words, Open width Washing Range removes unfixed dyestuff, gum, and other chemicals from the fabric.
- Secondly, Washing with tanks can carry out pre-washing, rinsing, and chemical treatment.
- Therefore, Open width Washing Range improves fabric quality.
- An effective squeezer between the washing unit gives maximum liquor separation from one bath to another.
- Thirdly, Each washing compartment with its force-spray system, re-circulation pump, filtering device, overflow, drain, and heating arrangement.
- Fourthly, the Open width Washing Range’s working width is to be made from 1500mm to 3500mm depending on the client’s need.
- Fifthly, ranging from 70 gsm/meter square up to 700 gsm/meter square of woven fabric can be processed on this machine.
- Sixth and most Important is Perfect synchronizing of linear speed hence tension-less and creaseless transport of fabric all along the process.
🔶 ADVANTAGES :
✅ Excellent Washing efficiency.
✅ Extremely sturdy construction.
✅ Quiet running.
✅ Low energy consumption.
✅ Ease of operation.
✅ Optional knife spray between each strand of fabric with supply from a separate pump.
✅ Circulation and counter flow arrangement to save water.
✅ Low maintenance.
✅ Quick and simple installation.
✅ Tight closing glass windows on the sides to provide easy access.
✅ Direct steam heating by perforated S S Pipes.
✅ S S bottom rolls running in self-aligning bush bearing.
SKU: n/a -
Dyeing Machinery
HT.HP. Soft Over Flow
HTHP Soft Over Flow is just like the HTHP Soft Flow machine with a bigger capacity & for heavy fabrics.
HTHP Soft Over Flow is Specially Designed to process Heavy and sensitive fabrics like Terry Towel, and Curtain Bedsheet of 100% Cotton knit and woven fabrics. In short, it’s a Terry towel dyeing machine.
HTHP Soft Over Flow can work as a Soft Overflow with minor adjustments.
A larger nozzle diameter, with a Higher volume & low-pressure nozzle design and inside Teflon sheet are helpful to move the fabric very smoothly and gently without damaging the cloth.
A specially develop online filter design helps to collect the Terry towel fumes.
🔸 Technical Specification
✅ Capacity: 50 to 2000 kg.
✅ The process has a sensitive fabric like Terry Towels, Curtain, Bed Sheet, 100% cotton knit & woven etc.
✅ Work as Soft flow or as overflow dyeing.
✅ High Temp. – Up to 140 ° C.
✅ The vessel makes of stainless steel 316 L.
✅ Specially developed a filter to collect towel fumes.
✅ Teflon Sheet inside the chamber for smooth fabric movement.
✅ High volume, Low-pressure soft nozzle with a larger diameter for heavy and Larger width fabrics
✅ Fabric drive reel with frequency controller.
SKU: D/HSO-1 -
Dyeing Machinery
Hydraulic Jigger
Hydraulic Jigger
Hydraulic Jigger is a piece of revolutionary equipment for open-width Scouring, Bleaching & Dyeing processes in batch form. One of the best Dyeing machinery with perfect dyeing results. Hydraulic Jigger has the following features:
- Firstly, Hydraulic Jigger’s Adjustable tension according to Fabric quality ensures perfect pre-treatment and dyeing irrespective of run lengths for the same shade/colour. In other words, Hydraulic Jigger dyes the Clothing rapidly with accuracy.
- Secondly, Hydraulic Jigger comes with closed chambers with doors that close while the operation is performing. Which gives it desired temperature in less time. Therefore, less wastage of resources.
- Thirdly, Consistent dyeing of the same shade for any number of times in the future, Moreover the highly efficient washing system saves washing time and precious Water. The uniform tension, process time, and ideal temperature contribute to the dying quality.
- Fourthly, Hydraulic Jigger controls these parameters resulting in fully controllable and reproducible shades. The controlled temperature and a steady circulation of dye liquid for flawless dyeing. PLC aided operation for repeatability. Suiting, shirting, and delicate fabrics such as rayon are best suited.
- Fifthly, the Hydraulic Jigger is available in 500kg and 1000kg capacity from 1200mm to 3000mm working width depending on the client’s need. Fabric ranging from 70 to 700 gsm/meter square of woven material may be dyed in a Hydraulic Jigger, making it ideal for Suiting, Shirting, and Delicate textile such as rayon.
Above all, flawless synchronisation of linear speed results in tension-free and crease-free fabric conveyance throughout the process.
🔸 Technical Specification
➡ Automatic reversal at the end of each cycle setting
➡ Spray washing through a selector switch
➡ Stopping the machine at the pre-determined sampling point
➡ Water filling through rotary switch
➡ Drain through a selector switch
➡ Digital Speed indication
➡ Speed setting through P L C
➡ Replenishing from dosing tank through valve
➡ Indirect steam heating through Heat Exchanger
➡ Temperature Controller.
➡ A valve adjusts the tension on the cloth.
➡ Soft Start & Stop
➡ Pendulation when adding and emptying liquid
➡ Touch Screen
➡ Specially designed software for the machine
SKU: n/a -
Accessories
A Frame
A-FRAME Trolley
A-Frame trolley is one of the most required Accessories in Textile Plant and Mills. A-frame’s objective is to carry the fabric and make it easy to manoeuvre inside the facility while different processes such as measuring, washing, cleaning, dyeing or printing, and finishing.
A-frame trolleys are also Utilised in rotating stations by simply adding an extension to them.
A-frame trolleys come in different sizes from 44 to 130 inches roller width depending on the customer. A-frame trolleys take less space than bucket/box-type trolleys. It gets easier to manage them and store them in one place.
Inshot A-Frame Tolleys are best to manage and store the grey to finished material in a clean and sorted way that helps to identify the fabric lot.
Many Textile mills and Export houses have been using it for a long time, making it reliable and one of the solutions to manage the fabric.
🔸 Technical Specification
✅ A FRAME’s top roll fabricate from M.S. Seamless Pipe (Ebonite quoting).
✅ The end shaft is RIB constructed or As per the buyer’s suggestion.
⭕ Cladding of S.S. Sheet on a batch roll. (Optional)
✅ The front side pooling system is a swivel-type M.S. fabricated bracket with 10″ x 2 wheels.
✅ The rare side is of fixed type 12″ x 3″ wheel.
✅ Batch coupling is fit on a batch roll for rotating.
✅ A-FRAME is manufactured from an M.S. channel (100/50mm) x 6mm wall thickness.
SKU: A/T-1
Related products
-
Dyeing Machinery
CP Dyeing
CP Dyeing
CP Dyeing is dyeing machinery to Dye Fabrics rapidly. Dye Fabric. This machine has the following features.
- First, it dyes the cloth with reactive colours. The CP Dyeing is installed with a small vat & shaped to allow fabrics an adequate contact time for absorbing dye bath through the high speed of cloth.
- In other words, CP Dyeing dyes the cloth rapidly, with less place required.
- Secondly, Reduced liquor volume is possible due to the fast exchange of fluid. Therefore, less wastage of resources.
- Thirdly, CP Dyeing‘s Roller width can be made from 1200mm to 3000mm depending on the client’s need.
🔶 Special Features:
✅ Versatile because it is equally suitable for Light and Heavy fabrics.
✅ Utilising of “Two Nip Two Dip” method ensures consistent colour penetration.
✅ The Top rubber roller is anti-deflecting construction.
✅ On Nips, pneumatic loading can be as much as 6 tons.
✅ Minimum loss of dye liquor because of low Dye liquor content in the trough.
✅ The main Batcher can batch cloth up to 1500mm Dia.
✅ Drive to both padder & Batcher by inverter-controlled AC Drive.
✅ Minimum tension between padder & Batcher is for perfect winding of cloth.
✅ The minimum distance between Padder & Batcher is to avoid oxidation.
✅ Machines are available from 1200mm to 3000mm roller width.
SKU: n/a -
Dyeing Machinery
Hydraulic Jigger
Hydraulic Jigger
Hydraulic Jigger is a piece of revolutionary equipment for open-width Scouring, Bleaching & Dyeing processes in batch form. One of the best Dyeing machinery with perfect dyeing results. Hydraulic Jigger has the following features:
- Firstly, Hydraulic Jigger’s Adjustable tension according to Fabric quality ensures perfect pre-treatment and dyeing irrespective of run lengths for the same shade/colour. In other words, Hydraulic Jigger dyes the Clothing rapidly with accuracy.
- Secondly, Hydraulic Jigger comes with closed chambers with doors that close while the operation is performing. Which gives it desired temperature in less time. Therefore, less wastage of resources.
- Thirdly, Consistent dyeing of the same shade for any number of times in the future, Moreover the highly efficient washing system saves washing time and precious Water. The uniform tension, process time, and ideal temperature contribute to the dying quality.
- Fourthly, Hydraulic Jigger controls these parameters resulting in fully controllable and reproducible shades. The controlled temperature and a steady circulation of dye liquid for flawless dyeing. PLC aided operation for repeatability. Suiting, shirting, and delicate fabrics such as rayon are best suited.
- Fifthly, the Hydraulic Jigger is available in 500kg and 1000kg capacity from 1200mm to 3000mm working width depending on the client’s need. Fabric ranging from 70 to 700 gsm/meter square of woven material may be dyed in a Hydraulic Jigger, making it ideal for Suiting, Shirting, and Delicate textile such as rayon.
Above all, flawless synchronisation of linear speed results in tension-free and crease-free fabric conveyance throughout the process.
🔸 Technical Specification
➡ Automatic reversal at the end of each cycle setting
➡ Spray washing through a selector switch
➡ Stopping the machine at the pre-determined sampling point
➡ Water filling through rotary switch
➡ Drain through a selector switch
➡ Digital Speed indication
➡ Speed setting through P L C
➡ Replenishing from dosing tank through valve
➡ Indirect steam heating through Heat Exchanger
➡ Temperature Controller.
➡ A valve adjusts the tension on the cloth.
➡ Soft Start & Stop
➡ Pendulation when adding and emptying liquid
➡ Touch Screen
➡ Specially designed software for the machine
SKU: n/a -
Dyeing Machinery
Multi-Nozzle Soft flow
Multi-Nozzle Soft Flow is a Low/High-Temperature dyeing machine technology that works as a “Soft flow” or as a “Jet dyeing” machine.
The main advantage of this development is to increase the machine’s flexibility and versatility to process all types of fabrics.
The soft nozzles in this new technological advancement have a large diameter, and the fixed nozzle has an individual flow control valve, whereas the main nozzle is adjustable.
By increasing and decreasing the gap of a nozzle, flow and pressure increase or decrease as per fabric quality demand.
To run Multi-Nozzle Soft Flow as a soft flow machine, increase the gap Which, subsequently decreases the pressure and increases water flow,
At the time, all three nozzles worked as Soft flow & water flow gets controlled individually by the control valve As per fabric quality demand.
To run The Multi-Nozzle Soft Flow as a “Jet dyeing” Machine lowering the gap of a nozzle which increases the pressure and decreases the water flow. That time close the soft-nozzle control valve.
🔸 Technical Specification
✅ Capacity: 25 to 400 kg. (Single Tube)
✅ Ultra Low Liquor Ratio – 1:1 (Wet Fabric)
✅ Dye –30 To 500 Grms./Mtr. Sq. Fabrics (Woven & Knitted Fabrics)
✅ High Temp. – Up to 140° C.
✅ Max. Fabric Speed – 400 Mtr./Min.
✅ Work as a Jet Dyeing or as Soft flow to meet the requirements of all types of fabric quality.
✅ Vessel: SS 316 L.
✅ Multiple soft nozzles.
SKU: D/MSF-1 -
Dyeing Machinery
HT.HP. Soft Over Flow
HTHP Soft Over Flow is just like the HTHP Soft Flow machine with a bigger capacity & for heavy fabrics.
HTHP Soft Over Flow is Specially Designed to process Heavy and sensitive fabrics like Terry Towel, and Curtain Bedsheet of 100% Cotton knit and woven fabrics. In short, it’s a Terry towel dyeing machine.
HTHP Soft Over Flow can work as a Soft Overflow with minor adjustments.
A larger nozzle diameter, with a Higher volume & low-pressure nozzle design and inside Teflon sheet are helpful to move the fabric very smoothly and gently without damaging the cloth.
A specially develop online filter design helps to collect the Terry towel fumes.
🔸 Technical Specification
✅ Capacity: 50 to 2000 kg.
✅ The process has a sensitive fabric like Terry Towels, Curtain, Bed Sheet, 100% cotton knit & woven etc.
✅ Work as Soft flow or as overflow dyeing.
✅ High Temp. – Up to 140 ° C.
✅ The vessel makes of stainless steel 316 L.
✅ Specially developed a filter to collect towel fumes.
✅ Teflon Sheet inside the chamber for smooth fabric movement.
✅ High volume, Low-pressure soft nozzle with a larger diameter for heavy and Larger width fabrics
✅ Fabric drive reel with frequency controller.
SKU: D/HSO-1
There are no reviews yet.
