Top Tube Soft Flow
Top Tube Soft flow dyeing machine very much suitable to process delicate woven & knitted fabrics. It’s soft nozzle decrease tension further avoid problems like crease marks, rope marks, shrinking etc.
Another benefit of this machine is its single vessel two chamber design reduce fabric loop length as well as processing time.
₹1,650,000.00
Compare
Top Tube Soft Flow
Top Tube Soft flow dyeing machine very much suitable to process delicate woven & knitted fabrics. It’s soft nozzle decrease tension further avoid problems like crease marks, rope marks, shrinking etc. Another benefit of this machine is its single vessel two chamber design reduce fabric loop length as well as processing time.
Technical Specification
- Capacity : 100 to 350Kg.
- Single Vessel 2 Chambers to Reduce loop length.
- Dye – 30 To 450 Grams/Meter. Sq. Fabrics (Woven & Knitted Fabrics)
- Liquor ratio: 1:8 (Wet fabric)
- High Temp. – Up to 140 ° C.
- Vessel made from – SS 316 L
- Specially design Soft Nozzles for Smooth and entangle free operation.
- Fabric drive reel with frequency controller.
Payment, Taxes and Delivery
Payment: 40% Advance & Balance against Proforma Invoice prior to dispatch.
Delivery: Delivery of machine is ideally comes within 4 to 6 weeks.
Freight: Will be paid by the customer.
Sales Tax: GST 18% (Domestic Orders) Or Vat 4% +1% No CST against form “H”( Export Orders).
Erection: Will be charged extra per machine over and above given price.
1. Select Product
Choose the required specification & submit the details.
2. Get Offer
Get a Detailed Offer.
3. Pay The Advance
Pay the advance amount as per agreed terms.
4. Product Under Construction
Product goes under Construction according agreed time.
5. Pay The Rest Amount
Pay the balance amount as your machine get ready to dispatch.
6. Shipment Initiated
Shipment option available through Manufacturer.
7. Installation
Finally, the product will be installed at your plant.
| Capacity | 100 Kgs, 125 Kgs, 200 Kgs, 250 Kgs, 300 Kgs, 350 Kgs |
|---|---|
| Fabric | WOVEN, KNITTED |
Based on 0 reviews
